福斯Flowserve Anchor Darling 800截止閥

點擊圖片查看原圖
品牌: Darling
Size: 2 1/2" - 24"
Pressure: class 150 - 1500
單價: 8888.00元/臺
所在地: 上海
有效期至: 長期有效
最后更新: 2017-07-16 22:41
瀏覽次數: 420
詢價
店鋪基本資料信息

產品詳細說明
Description
The Series 800 globe valve is a precision cast body and yoke assembly. It is an investment casting and offers smooth flow passages for minimum pressure dro and minimum turbulence.
Series 800 globe valves are provided with a quick-open style disc to provide throttling flow characteristics.
Series 800 globe valves are supplied with handwheel actuators. To operate these manual valves, turn the handwheel in a clockwise direction for closure and counter clockwise for opening.


Features and Benefits
Increased uptime via large radius curves in body design to ensure smooth transitions and eliminate abrupt changes in fluid direction
Broad application versatility in high-temperature, high-pressure applications enabled by a wide range of pressure and size options
Longer service life from body and plug designed to minimize cavitation
Available with functional qualifications per pressure classes 150 through 1500 for nuclear service

Size Range:
NPS 2 1/2 to 24
DN 65 to 600
Pressure Class Range:
150 to 1500
PN 25 to 260
Seating Material: Metal



關于福斯閥門的更多產品及應用,請關注 http://www.flowservevalve.gongboshi,com
